1000m Depth Water Well Drilling Machine 105mm - 800mm Dia 179KW Deep Well Drilling Rig

1000m Depth 105 - 800mm Diameter Water Well Drilling Machine Cummins 179KW

Machine Description

RCF1000C water well drilling machine is versatile and can meet the drilling needs of various terrains and formations such as mud drilling, air drilling and air foam drilling. Its compact design and small size make it suitable for drilling in limited spaces and facilitates transportation in tunnels. The drilling rig has two optional drive modes and has wide applicability. At the same time, telescopic masts or box - type masts are optional to meet the requirements of long casing drilling and improve work efficiency. In addition, the drilling rig is integrated with a visual pressure feeding system, which can accurately adjust the drilling pressure according to the drilling depth. Equipped with 4 hydraulic legs, it can be quickly leveled and transported without a crane. The rotating centralizer provides a spacious operating space. The optional external floating spindle can increase the service life of the drill pipe thread by 30 % . These features make this drill rig perform well in various environments and working conditions, making it a practical and efficient drilling rig equipment.

Technical Data

Advantage

RCF1000C water well drilling machine uses a 179 Cummins three-stage engine with electronically controlled fuel injection technology, which reduces fuel consumption and is environmentally friendly. The engine also has the function of automatically displaying fault codes for easy maintenance. The design of the hydraulic top drive head is mature and reliable. The large -  capacity bearing of the main shaft improves the load-bearing capacity and drilling accuracy. The sealing design ensures the sealing effect. The drilling rig is also equipped with a large-stroke telescopic drill mast to meet the subsequent drilling requirements of 6m and reduce the wear and tear of the drill frame. Hydraulic matching technology reduces system heat and fuel consumption, and the system pressure loss is small. The drilling pressure can be adjusted according to the weight of the drilling tool in the hole. The safety design includes multiple emergency stop buttons, and the centering plate can be replaced with wear - resistant sleeves to reduce pipeline wear.
