Remote Control HDD Drill Rig 62KW Horizontal Directional Drilling Equipment

Remote Control HDD Drill Rig 62KW Horizontal Directional Drilling Equipment

Remote Control HDD Drill Rig

HDD Drill Rig 62KW

HDD Horizontal Directional Drilling Equipment

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCHD-160

Contact Us
Request A Quote
Remote Control HDD Drill Rig 62KW Horizontal Directional Drilling Equipment
Product Details
Name:
HDD Drilling Rig
Model:
RCHD-160 HDD Drill Rig
Max. Push & Pull Force::
160KN/16T
Walking Speed:
2km/h
Highlight:

Remote Control HDD Drill Rig

,

HDD Drill Rig 62KW

,

HDD Horizontal Directional Drilling Equipment

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
It can be shipped by one 20" container
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
RELATED PRODUCTS
Good price Drilling Depth 60-80m Hydraulic Thrust Boring Machine With 32HP Diesel Engine online Video

Drilling Depth 60-80m Hydraulic Thrust Boring Machine With 32HP Diesel Engine

Get Best Price
Good price 60-80m Depth Small Hydraulic Thrust Boring Machine With 32HP Diesel Engine online Video

60-80m Depth Small Hydraulic Thrust Boring Machine With 32HP Diesel Engine

Get Best Price
Good price 60m Depth 32HP Diesel Engine Underground Horizontal Boring Machine Hdd Drilling Machine online Video

60m Depth 32HP Diesel Engine Underground Horizontal Boring Machine Hdd Drilling Machine

Get Best Price
Good price 150KGS Weight Small Directional Boring Machine For Trenchless Laying Of Various Pipelines online Video

150KGS Weight Small Directional Boring Machine For Trenchless Laying Of Various Pipelines

Get Best Price
Contact Us
Contact Now
Product Description

Remote Control Rubber Crawler Mounted HDD Drilling Rig 62KW Diesel Engine



Product Description



The RCHD - 160 hydraulic directional drill is an ideal choice for urban underground pipeline construction. This equipment is specially designed for the laying of underground pipelines and cables. It can efficiently, accurately and economically operate without causing damage to the surface and existing underground facilities. Complete the drilling mission. Thanks to its high-power engine and advanced control system, the RCHD - 160 can cope with complex geological conditions and ensure high operating efficiency. The device ' s user - friendly interface improves work efficiency, reduces costs, and mitigates environmental impact, making it the best choice for utility line installations.



Product Specifications



Model RCHD-160 Mini HDD Drill Rig
Rig weight 2.2t
Dimensions (L×W×H) 3700*1800*1200mm
Engine power 62kw Thunder Power
Max. push & pull force 160KN/16T
Traveling form Remote control
Walking speed 2km/h
Water injection system 160 type three-cylinder mud pump
Max. pressure of mud pump 2.8MPa
Max. flow of mud pump 160L/min
Entry angle 28°
Departure angle 20°
Climbing ability 35°
Torque 3200N.m



Product Features



The RCHD - 160 small horizontal directional drilling rig uses Weifan engine to provide powerful power and efficient operation. High-torque motor and rack - and - pinion drive system ensure stability and durability. The adjustable - angle boom adapts to different construction conditions. Construction machinery chassis, rubber tracks and high - speed travel motors improve mobility. Wired remote operation and two - speed swivel push - pull functionality improve visibility, safety and efficiency. High - quality main pumps, mud pumps and hydraulic valve groups ensure high performance and long life. Compact design fits into tight spaces and is ideal for urban underground projects



Product Image



Remote Control HDD Drill Rig 62KW Horizontal Directional Drilling Equipment 0Remote Control HDD Drill Rig 62KW Horizontal Directional Drilling Equipment 1Remote Control HDD Drill Rig 62KW Horizontal Directional Drilling Equipment 2Remote Control HDD Drill Rig 62KW Horizontal Directional Drilling Equipment 3
