Zinc-Coated Borehole Camera Borewell Inspection Camera For Accurate Geophysical Surveying Results

Zinc-Coated Borehole Camera Borewell Inspection Camera For Accurate Geophysical Surveying Results

Borewell Inspection Borehole Camera

Zinc-Coated Borehole Camera

Accurate Geophysical Surveying Borehole Camera

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RC-H300/H400/H500/H800/1200m/1500m/2000m

Contact Us
Request A Quote
Product Details
Monitor Size:
12” High Brightness LED Monitor, 210*310mm, Outdoor Visual, Screen Resolution 1027*768
Rotate:
360°
Probe Interface:
Connect The Probe, Transmit Video And Power
Product Features:
1.The Main Control Box Adopts 12V Direct Current, 220V AC,380V As The Working Power, The Whole Power Consumption Is Only 20W, 2.Lightweight: Electric Winch With Automatic Brake Device, Compact Structure, Compact Size, Durable, 3.360 Degrees Rotating Probe
Cable Material:
Custom Logging Cable
Measurement Range:
0-1000 Meters
Product Category:
Geophysical Survey Equipment
Video System:
8G SD Card Video System
Highlight:

Borewell Inspection Borehole Camera

,

Zinc-Coated Borehole Camera

,

Accurate Geophysical Surveying Borehole Camera

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Standard shipping
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
Product Description



Zinc-Coated Borehole Camera Borewell Inspection Camera For Accurate Geophysical Surveying Results

Product Description:

The main control box of the Borehole Camera is made from high-quality aluminum alloy, making it sturdy and durable for use in even the toughest conditions. This material ensures that the camera is long-lasting and able to withstand any wear and tear that may occur during use.

The borehole camera of the Geophysical Survey Equipment is available in two sizes, with the standard size being Φ65mm and the optional wide-angle camera being Φ50mm. The camera is waterproof, making it ideal for use in wet conditions or in submerged environments. The Borewell Inspection Camera is also designed to capture clear and high-quality images, ensuring that all data collected is accurate and reliable.

Features:

  • Product Name: Zinc-Coated Borehole Camera Borewell Inspection Camera For Accurate Geophysical Surveying Results
  • Detection Depth: 300m/400m/500m/800m/1000m
  • Type: Survey Equipment
  • Application: Geophysical Surveying
  • Split Docking Probe: Easy to exchange the probes of different size and specification
  • Data Interface: Can be written into well location, well number, can be self-calibration depth

Technical Parameters:

Product Category Geophysical Survey Equipment
Winch Type Electric Winch
Camera Pixels CCD Camera, 1200 TVL High-definition Low-light
Data Interface Can be written into well location, well number, can be self-calibration depth
Interface USB
Detection Depth 300m/400m/500m/800m/1000m
Display Size 12 inch LED monitor, Aspect ratio: 4:3, Contrast: 450:1, Brightness: 800cd/m2, Resolution: 1027 × 768, Power DC 12V,220V ,380V, Color system: PAL/NTSC/SECAM
Probe Pressure 1500m, Pressure 15Mpa
Depth Interface Connect the depth sensor
Lens Angle Side 360°


Applications:

RC-H300/H400/H500/H800/H1000 borehole camera is mainly used in underwater, borehole, water well drilling hole engineering, hydrology, mining, petroleum, geotechnical, civil and other units or departments. And it can be used to observe the characteristic of geologic body in drill hole, well hole, well drilling, oil well and pile foundation etc, such as rock structure, geological structure, rock strike, faults, fissures, dissection, underwater and undersea survey.

FAQ:

Here are some frequently asked questions about our RanCheng Geophysical Survey Equipment:

Q: What is the delivery time for RanCheng Geophysical Survey Equipment?

A: The delivery time for our equipment is 10-15 working days.

Q: What are the payment terms for purchasing RanCheng Geophysical Survey Equipment?

A: We accept T/T and Western Union payments for purchasing our equipment.

Q: What is the minimum order quantity for RanCheng Geophysical Survey Equipment?

A: The minimum order quantity for our equipment is 1 set.

Q: Where is the RanCheng Geophysical Survey Equipment manufactured?

A: Our equipment is manufactured in China.

Q: Is RanCheng Geophysical Survey Equipment certified?

A: Yes, our equipment is certified with CE and ISO 9001:2000.

Q: What is the supply ability of RanCheng Geophysical Survey Equipment?

A: Our supply ability is 100 sets per month.

Q: What is the price for RanCheng Geophysical Survey Equipment?

A: The price for our equipment is negotiable.

Q: What is the packaging for RanCheng Geophysical Survey Equipment?

A: Our equipment is packaged with standard shipping packaging.

Q: What models of Geophysical Survey Equipment does RanCheng offer?

A: We offer the RC-H300, RC-H400, RC-H500, RC-H800, RC-1200m, RC-1500m, and RC-2000m models.
