Portable Hydraulic Core Drilling Rig Core Drilling Machine For Easy Transportation And Assembly

Portable Hydraulic Core Drilling Rig Core Drilling Machine For Easy Transportation And Assembly

Easy Transportation Core Drilling Rig

Assembly Core Drilling Rig

Portable Hydraulic Core Drilling Rig

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCK400P

Contact Us
Request A Quote
Product Details
Drill Depth:
HTW:180mm,NTW: 400mm,BTW: 480m
Drilling Pipe Length:
1.5m
Diesel Engine:
42KW Yuchai
Rated Rotary Speed:
2400rpm
Lifting Force:
700KGS
Total Machine Weight:
1800KGS
Highlight:

Easy Transportation Core Drilling Rig

,

Assembly Core Drilling Rig

,

Portable Hydraulic Core Drilling Rig

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Standard shipping
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
Product Description

Portable Hydraulic Core Drilling Rig Core Drilling Machine For Easy Transportation And Assembly



Production:



The RCK400P portable hydraulic core drill is suitable for rope core drilling in medium and deep holes. It is compact in structure, lightweight in modular design and easy to disassemble. The RCK400P rig is particularly suitable for use in mountainous and remote areas and can be carried manually without having to build roads or destroy vegetation. The core drilling rig is designed with portability and environmental protection in mind, allowing it to operate efficiently in difficult terrain and ecologically sensitive areas. Its modular design is not only easy to transport, but also can be quickly assembled to meet a variety of field drilling needs, thus greatly improving work efficiency and adaptability.



Technical Parameters:



Drilling depth capacity









BTW 57.3mm 480m
NTW 73.3mm 400mm
HTW 91.3mm 180mm
Drilling pipe length 1.5m
Diesel engine Yuchai 4 cylinders Turbo diesel engine
Engine power 42KW X 2sets
Rated rotary speed 2400rpm
Hydraulic system


Rated pressure 21MPa
Rated flow 96L/min
Cooling system Water cooling
Top drive rotation head





Drilling angle 0-90
Maximum torque 400-600N.m
Maximum rotation speed 0-1200rpm
Feed travel 1.8m
Pull force 10T
Feeding force 6T
Winch



Rated rotary speed 100-240RPM
Lifting force 700KGS
Were Diameter 6mm
Were accommodation 500m
Hydraulic mud pump


model BW90
flow 30-90L/min
pressure 4-7Mpa
Hydraulic clamp holder B/N/H
Module Weight




Power module weight 350KGS X 2
Operating floor module weight 140KGS
Oil tank module weight 240KGS
Rotary head module weight 255KGS
Chassis module weight 260KGS
Total machine weight 1800KGS



Features:

  • High-performance engine: The core drilling rig adopts Yuchai high-performance National III turbocharged engine, integrated control system, enhanced power reserve, optimized system configuration, strong output power.
  • Hydraulic system: Hydraulic system adopts high pressure plunger pump, advanced constant power output and load induction control system to accurately control system pressure, which can fully cope with complex formation.
  • Power head: The power head adopts single-stage gear transmission structure and A6VM high-pressure plunger pump, the output torque is three times that of the traditional gear motor, and is equipped with thin-wall drilling tools, stable cutting and fast drilling speed.
  • Safety structure: Equipped with automatic telescopic combination mast and anti-pressure damage protection clamping mechanism, compact structure, safe and reliable.

Advantages:

  1. Lightweight Design: The core drilling rig features a modular design.
  2. High-Quality Materials: Over 90% of the framework is made from aviation aluminum.
  3. Quick Setup: Can be assembled and disassembled in just 20 minutes, making relocation easy.
  4. Efficient Drilling: Uses thin-wall rods for low resistance and fast penetration.
  5. Enhanced Control: Equipped with a long stroke cylinder, which is easier to control than traditional chain systems.
  6. Reliable Components: Incorporates globally leading brands to ensure stability and reliability.
  7. Cost-Efficient Operation: Eliminates the need for road and infrastructure construction, saving time and money.
  8. Hydraulic Coring: No drilling tower required, offering energy savings.
  9. Environmentally Friendly: Designed to minimize environmental impact.
  10. Low Consumption: Reduces operational costs, making it a highly popular portable core drilling rig for mineral exploration.

Application:

RCK400P hydraulic small core drilling rig is widely used in mineral exploration, infrastructure construction (i.e.railway, road and bridge, etc.), hydraulic and hydropower project, tunnel exploration and geographical investigation. It works particularly well in areas with complex geographic characteristics such as mountainous regions, forests and plateaus. It is the ideal drilling rig when operating in hard-to-accessories within a depth of 600 meters, executing small projects, conducting initial investigations and working on tight schedules.



Portable Hydraulic Core Drilling Rig Core Drilling Machine For Easy Transportation And Assembly 0



Portable Hydraulic Core Drilling Rig Core Drilling Machine For Easy Transportation And Assembly 1
