Home > products > Rotary Drilling Rig >
Auger Piling Pile Driver Breaker Rock Drill DTH Core Rotary

Auger Piling Pile Driver Breaker Rock Drill DTH Core Rotary

Rock Drill Pile Driver

DTH Core Rotary Pile Driver

Auger Piling Pile Driver

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCQ530

Contact Us
Request A Quote
Product Details
Working Mode:
Hydraulic Oil Cylinder Pressure
Model:
RCQ530
Kelly Bar Diameter:
340MM
Powerhead Max Output Torque:
70m/min
Dimension:
12000X3000X3500mm
Assisting Winch Max Lifting Force:
30KN
Max Working Pressure:
30Mpa
Working Width:
36M
Highlight:

Rock Drill Pile Driver

,

DTH Core Rotary Pile Driver

,

Auger Piling Pile Driver

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
It can be shipped by one 40" container
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
Product Description

Auger Piling Pile Driver Breaker Rock Drill DTH Core Rotary



Machine Introduction



Rotary pile drilling rig is a kind of large-scale construction machinery, which is mainly used to drill piles in the foundation of buildings, bridges, roads and other structures.


Our rotary drilling rig working range is for 500~1500mm pile diameter and within 50meters depth, adopts pressurized drilling mode, high drilling efficiency, good pore-forming quality; equiped with heavy duty crawler chassis, reliable quality, flexible in construction, suitable for various pile foundation works.


Technical Parameters



Model RCQ530
Working mode Hydraulic oil cylinder pressure
Drilling diameter  Φ500-Φ1500mm
Drilling depth  30m
Kelly bar diameter  340mm
Dimension  12000X3000X3500mm
The total weight  26T
Powerhead max output torque  130KN.m
Rotary speed  10-50r/min
Pressurized oil cylinder max pressure 130KN
Pressurized oil cylinder max lifting force 130KN
Main winch max lifting force 130KN
Main winch max lifting speed 70m/min
Assisting winch max lifting force 30KN
Assisting winch max lifting speed 60m/min
Pressurized oil cylinder max stroke 2500mm
Mast sidewards inclination ±4°
Mast forwards inclination
Max working pressure 30Mpa
pilot pressure 3.5Mpa
Travelling speed 5km/h
Working height 13500mm
Working width 3600mm
Diesel engine power  150KW ,Cummins



Machine Advantages



1,Flexible: the whole tonnage is small, simple operating, moving fast, convenient transition, etc features.



2,High returns: small investment, quick gains, economic advantages can not be replaced.



3,It has high drilling efficiency ,and After construction, It can quickly move to next worksite . flexible, convenient and efficient, is a national high-speed rail construction-specific piling machinery equipment.



4,power head

This bored piling rig Rotary head is with durable double motor ,with both strength and high speed ,it obtains many advantages in all working conditions ,working efficiency is 50% higher than other similar product



6,chassis

This rotary drilling rig adopts the self-developed hydraulic crawler type professional chassis,makes the machine working more steadily ,realizes 360 degree operation and ensures center balance





Machine Pictures



Auger Piling Pile Driver Breaker Rock Drill DTH Core Rotary 0Auger Piling Pile Driver Breaker Rock Drill DTH Core Rotary 1

Auger Piling Pile Driver Breaker Rock Drill DTH Core Rotary 2

Auger Piling Pile Driver Breaker Rock Drill DTH Core Rotary 3
