Four Wheels Trailer Type 25-27m³/Min Air Capacity LGCY-25/23-27/18K Air Compressor 2.3-1.8 Mpa Work Pressure

Four Wheels Trailer Type 25-27m³/Min Air Capacity LGCY-25/23-27/18K Air Compressor 2.3-1.8 Mpa Work Pressure

Product Description:

LGCY-25/23-27/18K is a powerful, fuel-efficient portable screw air compressor suitable for high-performance operations in abrasive blasting, construction and mining, with advanced filtration, cooling and oil-gas separation systems for reliable use in harsh environments. It adopts a triple oil-gas separation system to reduce the impact of too much or too little oil in the separator on the oil content of the compressed air. Clean compressed air is conducive to the safe operation of the host equipment.

Specific performance

◈SKY Patented screw host

Patented rotor profile, maximum efficiency, heavy duty design, SKY bearing, direct drive, principle skills, innovative design.

◈Special engine strong power

Equipped with Cummins 360HP heavy-duty special diesel engines, to achieve the best combustion state in the whole range of engine operation, so that the product has higher reliability, stronger power, better fuel economy.

◈Multiple air filtration systems

Effectively prevent the impact of harsh dust environment on the engine, the precision filter layer of the main air filter filters the remaining dust to ensure that the machine does not wear, and the safety filter element can make the machine do not stop the air filter maintenance to ensure the safe operation of the machine.

◈Efficient cooling system

Independent oil, water and air coolers with large diameter fan design for cold and hot weather.

◈Triple oil-gas separation system

Reduce the impact of too much or too little oil in the separator on the oil content of the compressed air, clean compressed air is conducive to the safe operation of the courage equipment.

◈Low temperature starting system (optional)

The pump of the fuel heater pumps the coolant in the engine body to the heat
exchange, the oil pump pumps the fuel in the tank to the burner and burns, through the continuous circulation of heat transfer, so that the temperature of the coolant and the lubricating oil of the whole machine continues to increase, to ensure the starting
performance of the diesel engine in the cold and plateau environment.

◈Remote start-stop, monitoring and positioning system (optional).

Technical Parameters:

Application area

LGCY Series Portable Screw Air Compressor are designed for a variety of segments like abrasive sandblasting, construction and mining where they are used to drive heavy pneumatic tools like jack hammer, pavement breaker, chipping hammer, pneumatic pumps, down-the-Hole drills, drilling rigs, water well drilling, sand blasting etc.
