Deep Geophysical Ground Resistivity Survey Underground Water Detector

Deep Geophysical Ground Resistivity Survey Underground Water Detector

Underground Water Detector

Underground Water Detector Survey

Deep Geophysical Ground Resistivity Survey

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RC-M300/500/1200/2000/3000-16D

Contact Us
Request A Quote
Product Details
Channel Input:
16 Channels Input Simultaneously, Maximum Electrode Spacing 2.5m
Channel Options:
1-14
Depth Options:
100/200/300/400/500/600/800/1200/2000/3000m
Scan Interval:
10-80
Connections:
Serial Port, Wifi, Bluetooth 4.0, USB (optional 4G)
Display:
10.1-inch IPS Wide-angle 178° Visual Touch Screen (1024×600)
Highlight:

Underground Water Detector

,

Underground Water Detector Survey

,

Deep Geophysical Ground Resistivity Survey

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Standard shipping
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
Product Description

Deep Geophysical Ground Resistivity Survey Underground Water Detector



Product Description:



The 16-channel real-time imaging water-finder is a real-time imaging intelligent water-finder jointly developed with the Guilin Institute of Hydrology and Geological Exploration. It uses 16-channel simultaneous input measurement to obtain a stable field source, which not only solves the problem of natural electric field changes at any time , And avoid the error caused by moving the electrode multiple times in the same profile, which solves the shortcoming of the repeated measurement data profile of the single-channel instrument.

The 16-channel real-time imaging water finder comes standard with 10.1-inch Android system touch screen real-time imaging, and the instrument screen, mobile phone screen, and computer screen are interoperable. 1-14 measurement channels can be selected, and wireless probes or water search can be optional The hoop rod can switch the measurement mode of MN electrode and TT probe, and the field operation is very convenient, which is generally recognized by customers.



Main advantages:


1.Automatic imaging:

The 10.1" Android touch screen is intelligent in real time into 2D, 3D and curved images.



2.Precise and stable:
The disadvantages of natural electromagnetic field sources, which are inconsistent in size and change from time to time, are solved and the accuracy is greatly improved.



3.Triple screen interoperability:
The instrument screen, mobile phone screen and computer screen are interoperable.



4.Intelligent and flexible:

1-14 channels are optional, and an electromagnetic probe can be selected for TT probe measurement mode, and it also supports wireless connection to find water golden hoop.

Technical Parameters:



Versions 300m-16D 500m-16D 1200m-16D 2000m-16D 3000m-16D
Max Depth (m) ≤300 ≤500 ≤1200 ≤2000 ≤3000
Channel Input 16 channels input simultaneously, maximum electrode spacing 2.5m
Channel Options 1-14
Depth Options Optional within the maximum depth, refer to 100/200/300/400/500/600/800/1200/2000/3000m
Scan Interval 10-80
Connections

Serial port, Wifi, Bluetooth 4.0, USB (optional 4G)

Display 10.1-inch IPS wide-angle 178° visual touch screen (1024×600)
OS Android 6.0.1
CPU ARM Cortex-A7 8-core CPU 2.0Hz
GPU OpenGL ES 2.0
Core Features Multiple options of depths, 2D/3D plotting, removable battery
Sensing Mode MN/TT
Frequency Range (hz) 1-8K 0.01-6K
Filtering Preset or intelligent frequency selection, analog + data filtering 1-16 times superposition optional
Discrim. 0.1mV±3% 0.01mV±2%
Acquisition Time (s) 60-3600 120-5400
Battery 800mA/H
Console Weight 1.85kg



Applications:

Underground water detector is a professional equipment  to determine the location, depth, and water yield of groundwater, to guide operations such as well drilling and water extraction, and to improve the success rate of well drilling. Detailed survey and general survey of regional hydrogeology.



Support and Services:



1,24/7 service by chat online and phone.

2,Lifelong and free technical support.

3,Service overseas: if you need, we can dispatch an engineer to your door.

Packing and Shipping:

delivery time :10-15days

standard exporting packing

FAQ:



Q:Are you the manufacturer?

A: Yes, we are the factory with more than 10 years of manufacturing experience.

Q:What is the warranty of our machine?
A:Our main machine enjoys a 1 year warranty. And we provide videos for machine install and operation.

Q: How long is your delivery time?
A: About 10-15 work days after receipt of the payment.


Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefits;

Q:Do you have any certificates for your machine?
A: All of our products coming with the certificates of CE and ISO 9001:2000.
