Adjustable Depth Single Channel Real Time Image Water Finder Water Detector

Adjustable Depth Single Channel Real Time Image Water Finder Water Detector

Adjustable Depth Water Finder

Single Channel Water Finder

Real Time Image Water Finder

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RC-M300/500/1200/2000/3000-16D

Contact Us
Request A Quote
Product Details
Channel Input:
16 Channels Input Simultaneously, Maximum Electrode Spacing 2.5m
Channel Options:
1-14
Depth Options:
100/200/300/400/500/600/800/1200/2000/3000m
Scan Interval:
10-80
Connections:
Serial Port, Wifi, Bluetooth 4.0, USB (optional 4G)
Display:
10.1-inch IPS Wide-angle 178° Visual Touch Screen (1024×600)
Highlight:

Adjustable Depth Water Finder

,

Single Channel Water Finder

,

Real Time Image Water Finder

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Standard shipping
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
Product Description

Adjustable Depth Single Channel Real Time Image Water Finder Water Detector



Product Description:



Natural electrical water detector uses the natural electric field as the working source, utilizes the difference in electrical conductivity of underground rocks or groundwater, measures multiple electric field components of different frequencies in the natural electric field on the ground, and analyzes the abnormal changes caused by different geological structures according to the changing laws of the electric field, thereby solving geological problems through electrical exploration.



Features:



1. Apply to multiple and complex terrain exploration



2. The instrument can automatic mapping and get result on site



3. Profile map shows aquifer and depth



4. Expert remote assistance to analysis well location



5. Inexperienced people can learn the operation in 5 minutes



Technical Parameters:



Versions 300m-16D 500m-16D 1200m-16D 2000m-16D 3000m-16D
Max Depth (m) ≤300 ≤500 ≤1200 ≤2000 ≤3000
Channel Input 16 channels input simultaneously, maximum electrode spacing 2.5m
Channel Options 1-14
Depth Options Optional within the maximum depth, refer to 100/200/300/400/500/600/800/1200/2000/3000m
Scan Interval 10-80
Connections

Serial port, Wifi, Bluetooth 4.0, USB (optional 4G)

Display 10.1-inch IPS wide-angle 178° visual touch screen (1024×600)
OS Android 6.0.1
CPU ARM Cortex-A7 8-core CPU 2.0Hz
GPU OpenGL ES 2.0
Core Features Multiple options of depths, 2D/3D plotting, removable battery
Sensing Mode MN/TT
Frequency Range (hz) 1-8K 0.01-6K
Filtering Preset or intelligent frequency selection, analog + data filtering 1-16 times superposition optional
Discrim. 0.1mV±3% 0.01mV±2%
Acquisition Time (s) 60-3600 120-5400
Battery 800mA/H
Console Weight 1.85kg



Applications:

As a groundwater finder, this device enables you to identify the presence of water resources accurately. Its ability to conduct detailed geophysical surveys empowers you to locate potential water reservoirs, ensuring efficient and successful water exploration missions.



Support and Services:


Is it difficult to operate?

---The device is simple to operate and can be used without any experience.
There are related U disks with detailed information in the box.

Guide for After-sale Service

> 1-year guarantee-if using of the product is influenced due to quality problem, you may receive guarantee of the product within 1 year after the date of purchase;

> Lifetime maintenance-lifetime maintenance service is implemented on all factory series products. We offer maintenance of machine which surpasses the maintenance period or has manual damage with material and lab
