Name: Factory Price 1000m Depth Water Well Drilling Rig Machine With 194KW Cummins in Stock
Brand: Henan Rancheng Machinery Co., Ltd.
SKU: RCF1000C
Availability: InStock

Home > products > Water Well Drilling Machine >

Factory Price 1000m Depth Water Well Drilling Rig Machine With 194KW Cummins in Stock

194KW Water Well Drilling Machine

1000m Water Well Drilling Machine

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCF1000C

Request A Quote

Product Details

Name:

Multifunctional Water Well Drilling Rig

Model:

RCF1000C Crawler Mounted

Drilling Depth(M):

1000

Diameter(MM):

800

Engine:

179KW Cummins

Weight:

13000KG

Highlight:

194KW Water Well Drilling Machine

1000m Water Well Drilling Machine

Payment & Shipping Terms

Minimum Order Quantity

Price

Negotiable

Packaging Details

It can be shipped by one 40" container

Delivery Time

10-15 working days

Payment Terms

T/T, Western Union

Supply Ability

100sets per Month

Max 150 Meters Protable RCF150S Water Well Drilling Machine

Get Best Price

Video

350m Drilling Depth Rubber Caterpillar Track Water Well Drilling Rig Pneumatic Rubber Crawler Drilling Rig

Get Best Price

Video

350m Drilling Depth 91KW Yuchai Engine Water Well Drilling Rig 22T Lifting Force

Get Best Price

Video

Compact And High Efficiency 150 Meter Water Well Drilling Rig

Get Best Price

Contact Now

Product Description

Factory Price 1000m Depth Water Well Drilling Rig Machine With 194KW Cummins in Stock

Machine Description

The RCF1000C industrial borehole drilling machine is a next-generation down-the-hole drilling rig developed by Rancheng Machinery to meet the demands of modern resource exploration. Equipped with a powerful 194KW Cummins engine, it delivers an impressive drilling depth capacity of up to 1000 meters and supports drilling diameters ranging from 140mm to 500mm. With a robust lifting force of 36 tons, the RCF1000C is built to tackle a variety of challenging geological conditions, including silt, quicksand, weathered rock, and pebble layers.

This model utilizes an advanced hydraulic control system that significantly reduces operator labor, enhancing both efficiency and ease of use. Designed for minimal noise and exceptional load resistance, it combines high performance with cost-efficiency. The RCF1000C is ideal for applications such as resource exploration, hydrological drilling, civil water well construction, and agricultural irrigation projects, providing a reliable solution for a broad range of drilling operations.

Technical Data

Bore diameter(hammer)	140-500mm
Bore depth	1000m
Air consumption	17-42m³/min
Air pressure	1.7-3.5Mpa
Pipe diameter	102/108/114mm
Pipe length	1m/2m/3m/6m
Lifting force	36T
Lifting speed	3m/min
feeding speed	0.5-5m/min
Fast lifting speed	20m/min
Fast feeding speed	40m/min
One-time advance length	6.6m
Max torque of rotary	9000-14000Nm
Rotary speed	45-140r/min
Hoist lifting capacity	2T
Mud Pump flow	850L/min (option)
High hydraulic leg	1.7m
Feeding efficiency	15-35m/h
Travel speed	2.5Km/h
Climb ability	30°
Dimension(LWH)	6300×2300×2950mm
weight	13000Kg
Diesel engine	194KW Cummins engine
Drilling way	Air compressor drilling or mud pump drilling

Advantage

1,it drill 1000m depth ,140-800mm diameter

2,it is hydraulic system operation ,easy to operate

3,it is 194KW cummins diesel engine ,convenient to use in the place without electricity

4,due to the full hydraulic and top-drive slewing propulsion lifting, it is suitable for various drilling processes and various drilling tools,with convenient and flexible control, fast drilling speed, and short auxiliary time, so the operation efficiency is high

5,it can drill clay ,soil ,hard rock etc stratum, and can use max 6 meters of drill pipe.

6,this deep well drilling rig is mainly used for well drilling in resource exploration and hydrology wells, civil use water well, agriculture irrigation etc projects.
