160m Portable Water Well Drilling Machine Powered By 35HP Engine
Product Description:
Introducing the RCS260C Portable Deep Well Drilling Machine – your ultimate solution for efficient and versatile drilling needs. Designed with a compact layout and a reasonable structure, this state-of-the-art machine is engineered to tackle a variety of drilling applications, making it an essential tool for both professionals and DIY enthusiasts alike.
The RCS260C is equipped with a powerful water pump that enhances its performance, ensuring effective slag removal during the drilling process. This feature not only improves efficiency but also prolongs the lifespan of the machine, allowing you to focus on your project without interruptions. Whether you are looking to drill geothermal wells, farm irrigation systems, or water wells for your home and garden, the RCS260C is up to the task.
With the capability to drill diameters ranging from 100mm to an impressive 450mm, and a maximum depth of 160m, this portable drilling machine is versatile enough to handle various strata, including sand, soil, clay, and soft rock. For those requiring larger boreholes, the RCS260C can accommodate drilling diameters of up to 500mm, making it suitable for a wide range of applications.
The RCS260C is not just about power; it’s also about portability. Its compact design allows for easy transportation and setup, making it ideal for remote locations or tight spaces. Whether you are a contractor, farmer, or homeowner, the RCS260C Portable Deep Well Drilling Machine is your go-to solution for reliable and efficient drilling. Invest in the RCS260C today and experience the difference in your drilling projects!
Features and Advantages
1. Lightweight, energy-saving.it is one small hydraulic bore well drilling rig
2. Patented product, unique design, and simple drilling structure;
3. Easy to transport and can learn how to handle the drilling rig in a short time;
4. Can drill through hard stratum, unless thick rock layer ;
Technical Parameters:
| Model of drilling machine |
RCS260C |
| Walking way |
Rubber crawler mounted |
| Drilling machine overall dimension(mm) |
2300*1080*2000 |
| Weight of Drilling machine (kg) |
1000 |
| Drill rod diameter (mm) |
Ø64 |
| Drill rod length(mm) |
1500 |
| Rod change method |
Full automatic screw thread |
| Drilling depth(m) |
160 |
| Diesel Motor Power (Hp/kw) |
35HP /25.8KW |
| Drilling method |
Percussive and rotating type |
| Drilling hole diameter(mm) |
Within Ø 450mm |
| Stroke distance (mm) |
2000 |
| Hosting capacity (kg) |
4000KG |
