Ground Water Detector Geophysical Water Survey Equipment 1200m Borehole Water Detector
Production Description:
ISO9001 & CE Certified 2000m 16 Multi Channel 100M-300M depth 3D Touch screen deep underground water detector is based on over 47 years R&D design and exploration, which realize the technology that you can use the mobile phone or tablet PC to do complex data calculation, then the graphs will automatic form in the touch screen mainframe, store in the cloud, and you can communicate with experts advisors on line about your graphs.
Besides, if use our probes to measure, then you can wirelessly detect. And in the “MN input”, you can use traditional MN cable lines or wireless sensor to measure. If with wireless sensor, you don’t have to cabling and can just measure by walk and stop, free of USB disk, detection button. Automatically mapping by mobile phone, communicating with experts advisors online, uploading the data into cloud and store permanently.
Main advantages:
Automatic imaging:The 10.1" Android touch screen is intelligent in real time into 2D, 3D and curved images.
Precise and stable:
The disadvantages of natural electromagnetic field sources, which are inconsistent in size and change from time to time, are solved and the accuracy is greatly improved.
Triple screen interoperability:
The instrument screen, mobile phone screen and computer screen are interoperable.
Technical Parameters:
| Versions |
300m-16D |
500m-16D |
1200m-16D |
2000m-16D |
3000m-16D |
| Max Depth (m) |
≤300 |
≤500 |
≤1200 |
≤2000 |
≤3000 |
| Channel Input |
16 channels input simultaneously, maximum electrode spacing 2.5m |
| Channel Options |
1-14 |
| Depth Options |
Optional within the maximum depth, refer to 100/200/300/400/500/600/800/1200/2000/3000m |
| Scan Interval |
10-80 |
| Connections |
Serial port, Wifi, Bluetooth 4.0, USB (optional 4G)
|
| Display |
10.1-inch IPS wide-angle 178° visual touch screen (1024×600) |
| OS |
Android 6.0.1 |
| CPU |
ARM Cortex-A7 8-core CPU 2.0Hz |
| GPU |
OpenGL ES 2.0 |
| Core Features |
Multiple options of depths, 2D/3D plotting, removable battery |
| Sensing Mode |
MN/TT |
| Frequency Range (hz) |
1-8K |
0.01-6K |
| Filtering |
Preset or intelligent frequency selection, analog + data filtering 1-16 times superposition optional |
| Discrim. |
0.1mV±3% |
0.01mV±2% |
| Acquisition Time (s) |
60-3600 |
120-5400 |
| Battery |
800mA/H |
| Console Weight |
1.85kg |
Support and Services:
1,24/7 service by chat online and phone.
2,Lifelong and free technical support.
3,Service overseas: if you need, we can dispatch an engineer to your door.
Packing and Shipping:
delivery time :10-15days
standard exporting packing
FAQ:
Q:Are you the manufacturer?
A: Yes, we are the factory with more than 10 years of manufacturing experience.
Q:What is the warranty of our machine?
A:Our main machine enjoys a 1 year warranty. And we provide videos for machine install and operation.
Q: How long is your delivery time?
A: About 10-15 work days after receipt of the payment.
Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefits;
Q:Do you have any certificates for your machine?
A: All of our products coming with the certificates of CE and ISO 9001:2000.
