Small Hydraulic Drill Cylinder 160m Depth Water Digger Machine Crawler Mounted Water Well Drilling Rig For Sale
Product Description:
This water well drilling rig is mainly used in geothermal drilling, agricultural irrigation, home yard, garden, water well drilling and drilling, etc. The drilling diameter ranges from 70 to 450 mm, and the maximum depth can reach 160 meters. It can also be used for piling of small buildings such as farms or factories, and the drilling diameter can reach 450 mm, which can be applied to different layers such as sand, soil, clay, soft rock, etc.
Features:
1. Lightweight, energy-saving, high efficiency, fast operation speed; can drill through hard strata, except thick rock strata;
2. Patented product, unique design, simple drilling structure. Easy to transport, can be learned in a short time, one person can operate, reducing labor intensity.
Technical Parameters:
| Model of drilling machine |
RCS260C |
| Walking way |
Rubber crawler mounted |
| Drilling machine overall dimension(mm) |
2300*1080*2000 |
| Weight of Drilling machine (kg) |
1000 |
| Drill rod diameter (mm) |
Ø64 |
| Drill rod length(mm) |
1500 |
| Rod change method |
Full automatic screw thread |
| Drilling depth(m) |
160 |
| Diesel Motor Power (Hp/kw) |
35HP /25.8KW |
| Drilling method |
Percussive and rotating type |
| Drilling hole diameter(mm) |
Within Ø 450mm |
| Stroke distance (mm) |
2000 |
| Hosting capacity (kg) |
4000KG |
Applications:
The RCS260C portable water well drilling rig is mainly used for geothermal drilling, agricultural irrigation, gardening, water wells and drilling holes, etc., with a depth of up to 160 meters. It can also be used for piling small buildings, such as farms or factories.
Support and Services:
1,24/7 service by chat online and phone.
2,Lifelong and free technical support.
3,Service overseas: if you need, we can dispatch an engineer to your door.
Packing and Shipping:
delivery time :10-15days
standard exporting packing
FAQ
Q:Are you the manufacturer?
A: Yes, we are the factory with more than 10 years of manufacturing experience.
Q:What is the warranty of our machine?
A:Our main machine enjoys a 1 year warranty. And we provide videos for machine install and operation.
Q: How long is your delivery time?
A: About 10-15 work days after receipt of the payment.
Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefits;
Q:Do you have any certificates for your machine?
A: All of our products coming with the certificates of CE and ISO 9001:2000.
