RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine

RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine

Hydraulic Small Rotary Drilling Machine

Small Rotary Drilling Machine

Lifting Force 120KN Rotary Drilling Rig

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCQ515M

Contact Us
Request A Quote
RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine
RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine
Product Details
Name:
Hydraulic Small Rotary Drilling Rig
Model:
RCQ515M
Bore Depth:
15m
Drilling Diameter:
500-1200mm
Power Head Torque (KN.m):
45KN.m
Main Winch Max Lifting Force:
120KN
Highlight:

Hydraulic Small Rotary Drilling Machine

,

Small Rotary Drilling Machine

,

Lifting Force 120KN Rotary Drilling Rig

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
It can be shipped by one 40" container
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
RELATED PRODUCTS
Good price RCQ515M Mini Pile Drilling Rig Drilling Depth 15m Hydraulic Small Rotary Drilling Machine online Video

RCQ515M Mini Pile Drilling Rig Drilling Depth 15m Hydraulic Small Rotary Drilling Machine

Get Best Price
Good price Hydraulic Compact Mini Rotary Pile Drilling Rig For Small Scale Drilling Operations online Video

Hydraulic Compact Mini Rotary Pile Drilling Rig For Small Scale Drilling Operations

Get Best Price
Good price RCQ-10C Hydraulic Mini Pile Drilling Rig 10m Depth With 36KW Kubota Engine Sany SY60C Excavator Chassis online Video

RCQ-10C Hydraulic Mini Pile Drilling Rig 10m Depth With 36KW Kubota Engine Sany SY60C Excavator Chassis

Get Best Price
Good price RCQ-10C Hydraulic Mini Pile Drilling Rig 10m Depth With 10-45RPM R/Min Rotary Speed online Video

RCQ-10C Hydraulic Mini Pile Drilling Rig 10m Depth With 10-45RPM R/Min Rotary Speed

Get Best Price
Contact Us
Contact Now
Product Description

RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine

Machine Introduction

The small hydraulic rotary drilling rig RCQ515m adopts pressure drilling method, with a maximum rotary drilling depth of 15 meters. Equipped with drilling tools of different specifications, the pile hole diameter can reach between 500 and 1200 mm.



This small water diversion device has high drilling efficiency and can be quickly transferred to the next work site after completion. It is flexible, practical and efficient. This is a mechanical piling equipment designed for national high-speed railway construction.



Technical Parameters

Drilling diameter Φ500-Φ1200mm Drilling depth 15m
Diesel engine

Yuchai 95KW
Powerhead torque (KN.m) 45KN.m
Rotary speed (r/min) 17-45RPM
Pressurized oil cylinder max pressure 100KN
Pressurized oil cylinder max lifting force 100KN
Pressurized oil cylinder max Stroke 2000mm
Main winch max lifting force 120KN
Main winch max lifting speed 60m/min
Main winch rope diameter 20mm
Assisting winch max lifting force 10KN
Assisting winch max lifting speed 60m/min
Assisting winch rope diameter 16mm
Travel speed 3km/h
Max climbing gradient 30°

Min ground clearance

 400mm

System working pressure

32Mpa
Machine dimension 9.8X2.5X3.35m Weight

19KGS





Application:



The drilling rig is mainly used for soft soil piles in foundations, seaports, bridges, reservoirs, national defense construction, etc. It is widely used in rotary drilling rigs, pile foundation construction, drilling engineering, geological exploration, blasting and other construction projects.



Machine Pictures

RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine 0RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine 1RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine 2RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine 3RCQ515M 45KN.M Power Head Torque Hydraulic Small Rotary Drilling Machine 4
