High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine

High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine

High performance Water Well Drilling Machine

RCF180S Water Well Drilling Machine

Mini Water Well Drilling Machine

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCF180S

Contact Us
Request A Quote
High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine
High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine
Product Details
Name:
RCF180S
Drilling Depth:
180m
Once-time Advance Length:
90-300mm
Rotary Speed:
45-65r/min
Diesel Engine:
77.3KW Yuchai Engine
Max Torque Of Rotary:
4000-4600Nm
RCF180S Mini Water Drilling Machine Is Very Powerful ,it Can Drill Max 180m Depth , This Small Water:
76/89mm
Weight:
2700kg
Lifting Force:
15T
Highlight:

High performance Water Well Drilling Machine

,

RCF180S Water Well Drilling Machine

,

Mini Water Well Drilling Machine

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
It can be shipped by one 20" container
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
RELATED PRODUCTS
Good price Max 150 Meters Protable RCF150S Water Well Drilling Machine online Video

Max 150 Meters Protable RCF150S Water Well Drilling Machine

Get Best Price
Good price 350m Drilling Depth Rubber Caterpillar Track Water Well Drilling Rig Pneumatic Rubber Crawler Drilling Rig online Video

350m Drilling Depth Rubber Caterpillar Track Water Well Drilling Rig Pneumatic Rubber Crawler Drilling Rig

Get Best Price
Good price 350m Drilling Depth 91KW Yuchai Engine Water Well Drilling Rig 22T Lifting Force online Video

350m Drilling Depth 91KW Yuchai Engine Water Well Drilling Rig 22T Lifting Force

Get Best Price
Good price Compact And High Efficiency 150 Meter Water Well Drilling Rig online Video

Compact And High Efficiency 150 Meter Water Well Drilling Rig

Get Best Price
Contact Us
Contact Now
Product Description

High-performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine
Machine Description

The RCF180S crawler water well drill is an excellent device. It is compact and powerful. Despite its relatively small footprint, it has a maximum drilling depth of up to 180 meters and a lifting force of up to 15 tons.

The rig is powered by a 77.3-kW Yuchai engine. Thanks to this engine, it can work in conjunction with a mud pump and an air compressor, allowing it to flexibly adapt to different drilling needs.
One of its highlights is the rubber crawler design. This allows the rig to move easily even on rough terrain, providing excellent maneuverability.

In addition, the RCF180S can also be equipped with advanced remote control technology. This technology enables the operator to remotely control the movement and operation of the rig, adding extra convenience and flexibility to the drilling process.



Technical Parameters

Bore diameter(hammer)90-300mm
Bore depth180m
Air consumption17-31m³/min
Air pressure1.7-2.5Mpa
Once-time advance length2.4m
Pipe diameter76mm/89mm
Pipe length2m
Push force4T
Lifting force15T
Max torque of rotary4000-4600Nm
Rotary speed45-65r/min
Mud Pump flow200L/min (option)
Feeding efficiency10-35m/h
Travel speed2.5Km/h
Climb ability30°
Dimension(L*W*H)2300×1200×1900mm
weight2700kg
Diesel engine77.3KW Yuchai engine


Feature:

1,Small size, light weight ,Compact structure,and flexible operation.
this drilling machine weight is only 2700KGS ,the machine size is 2300X1200X2900mm.
2,it is DTH pneumatic water drilling rig ,two motors rotary head ,top driving ,drill with both mud pump and air compressor ,The double rotation motor increased the rotary torque and revolving speed.
3,big powerful and ability ,it use 77.3KW Yuchai engine ,it can drill max 180m depth ,90-300mm borehole.
4,it is rubber crawler mounted type ,easy to move.
5,full hydraulic legs ,very convenient to transport by truck ,very stable in drilling job.

Image Display

High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine 0High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine 1High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine 2
High Performance Yuchai 180m Bore Depth RCF180S Mini Water Well Drilling Machine 3
