Name: 200m Truck Mounted Water Well Drilling Rig with 3400mm Feed Stroke
Brand: Henan Rancheng Machinery Co., Ltd.
SKU: RCF200T Truck Mounted Water Well Drilling Rig
Price: 150,000.00 USD
Availability: InStock

Home > products > Water Well Drilling Rig >

200m Truck Mounted Water Well Drilling Rig with 3400mm Feed Stroke

200m water well drilling rig

truck mounted drilling rig

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCF200T Truck Mounted Water Well Drilling Rig

Request A Quote

Product Details

Name:

Water Well Drilling Rig

Model:

RCF200T Truck Mounted Water Well Drilling Rig

Bore Diameter:

140-350mm

Bore Depth:

200m

Dimension:

8900*2100*3300mm

The Total Weight:

12T

Feed Stroke:

3400mm

Travel Speed:

80km/h

Highlight:

200m water well drilling rig

truck mounted drilling rig

Payment & Shipping Terms

Minimum Order Quantity

Price

USD100000-USD200000

Packaging Details

It can be shipped by ro-ro ship

Delivery Time

10-15 working days

Payment Terms

T/T,Western Union

Supply Ability

100sets per Month

RCF200T Hydraulic Water Well Drilling Machine/200m Truck Mounted Water Well Drilling Rig/6X4 Truck Mounted Rig

Get Best Price

Video

Hydraulic Tricycle Mounted Water Well Drilling Rig Drill Depth 400m with Cummins 170 HP Load Vehicle Engine

Get Best Price

Video

Hydraulic Tricycle Mounted Water Well Drilling Rig 1.7-3.5Mpa Wind Pressure

Get Best Price

Video

280m Depth Truck Mounted Water Well Drilling Rig 210 HP Load Vehicle Engine

Get Best Price

Contact Now

Product Description

RCF200T Truck Mounted Water Well Drilling Rig with 3400mm Feed Stroke

Key Features

Enhanced pneumatic power for improved drilling speed
Advanced hydraulic technology for efficient operation
Low fuel consumption with high torque performance
Convenient well inclination adjustment
Suitable for various drilling applications including resource exploration and agricultural irrigation

Technical Specifications

Attribute	Value
Model	RCF200T Truck Mounted Water Well Drilling Rig
Bore Diameter	140-350mm
Bore Depth	200m
Feed Stroke	3400mm
Drilling Type	Mud pump drilling and air DTH drilling
Rotary Torque	5600Nm
Lifting Power	12T
Truck Chassis	DONGFENG
Diesel Engine	Cummins 180HP
Dimension	8900×2100×3300mm
Total Weight	12T
Travel Speed	80km/h

Product Description

The RCF200T is a new generation of down-the-hole drilling rig independently developed with enhanced pneumatic power that significantly improves drilling speed. This truck-mounted water well drilling rig incorporates the latest hydraulic technology, offering superior performance with low fuel consumption, high torque, and convenient well inclination adjustment.

Ideal for various applications including resource exploration, hydrology surveys, civil engineering projects, and agricultural irrigation systems, this rig delivers reliable performance in diverse geological conditions.

Machine Gallery
