Name: This Groundwater Detector Can Reach A Maximum Depth Of 3000 Meters
Brand: Henan Rancheng Machinery Co., Ltd.
SKU: RC-M300/500/1200/2000/3000-16D
Availability: InStock

Home > Products > Geophysical Survey Equipment >

This Groundwater Detector Can Reach A Maximum Depth Of 3000 Meters

groundwater detector 3000 meters depth

geophysical survey equipment groundwater detection

deep groundwater detector for surveys

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RC-M300/500/1200/2000/3000-16D

Request A Quote

Product Details

Model:

RC-M1200

Depth:

2000m

Weight:

2KG

Channel Options:

Frequency Range:

Discrim:

0.1mV

Highlight:

groundwater detector 3000 meters depth

geophysical survey equipment groundwater detection

deep groundwater detector for surveys

Payment & Shipping Terms

Minimum Order Quantity

Price

Negotiable

Packaging Details

Standard shipping

Delivery Time

10-15 working days

Payment Terms

T/T, Western Union

Supply Ability

100sets per Month

300m Geophysical Equipment Borehole Water Well Log Tool Apparent Resistivity Measuring Logging System

Get Best Price

Video

Geophysical Well Logs Water Well Logging Equipment Well Logging Tool, Borehole Logging Equipment Geotechnical Borehole Survey Tool For Sale

Get Best Price

Video

Digital Logging System Specially Designed For The Convenience Of Field Work

Get Best Price

Video

300m Geophysical Equipment Borehole Water Well Log Tool 1% (Scale) Apparent Resistivity Measurement Accuracy

Get Best Price

Contact Now

Product Description

Groundwater Detector with 3000 Meter Maximum Depth

Product Overview

This ISO9001 certified 16-channel 3D touchscreen deep groundwater detector covers a depth range of 100 to 3000 meters and features multiple invention patents. The device effectively addresses problems such as unstable and transient variations in natural electric field intensity.

Key Innovation: Features field source correction technology described in "Geophysical Method for Earth Electromagnetic Field Source Correction and Measurement Device" (Patent Numbers ZL201320054153.5 and ZL201320303919.9).

Advanced Features

Integrated Core Module: High-performance processor running various algorithms for enhanced anti-interference capabilities and stable, accurate detection data in diverse environments
User-Friendly Operation: 10.1-inch touchscreen with 5-minute setup, supporting repeated measurements and automatic generation of 2D/3D color maps and curve graphs
Flexible Measurement Modes: Adjustable depth and channel settings with MN and TT measurement mode switching
Remote Data Sharing: Multi-device support including mobile phones and computers with secure account-based data access

Technical Advantages

The RC-M1200 16-channel underground water detector employs real-time imaging technology, developed in collaboration with the Guilin Institute of Hydrology and Geological Exploration. Its innovative design allows for stable field source measurement, effectively addressing the inconsistencies of natural electric field intensity while minimizing errors associated with repeated measurements.

Technical Specifications

Versions	300m-16D	500m-16D	1200m-16D	2000m-16D	3000m-16D
Max Depth (m)	≤300	≤500	≤1200	≤2000	≤3000
Channel Input	16 channels input simultaneously, maximum electrode spacing 2.5m
Channel Options	1-14
Depth Options	Optional within maximum depth: 100/200/300/400/500/600/800/1200/2000/3000m
Scan Interval	10-80
Connections	Serial port, Wifi, Bluetooth 4.0, USB (optional 4G)
Display	10.1-inch IPS wide-angle 178° visual touch screen (1024×600)
OS	Android 6.0.1
CPU	ARM Cortex-A7 8-core CPU 2.0Hz
GPU	OpenGL ES 2.0
Core Features	Multiple depth options, 2D/3D plotting, removable battery
Sensing Mode	MN/TT
Frequency Range (hz)	1-8K	0.01-6K
Filtering	Preset or intelligent frequency selection, analog + data filtering 1-16 times superposition optional
Discrimination	0.1mV±3%	0.01mV±2%
Acquisition Time (s)	60-3600	120-5400
Battery	800mA/H
Console Weight	1.85kg
