RCF200T Truck-Mounted Water Well Drilling Rig
A high-performance hydraulic drilling rig with 200-meter drilling capacity, designed for efficient water well and foundation engineering applications.
Product Overview
The RCF200T vehicle-mounted drilling rig is a modern, energy-efficient hydraulic system equipped with a 260 horsepower engine. Featuring propulsion and lifting cylinders with a high-impact downhole hammer, it delivers exceptional drilling performance with minimal energy consumption.
Application Versatility
This multi-functional rig is engineered for diverse foundation engineering needs including agricultural and industrial water wells, building foundations, geological exploration, geothermal wells, monitoring wells, hydropower projects, dike anti-seepage, foundation reinforcement, open-pit mining, and anchoring grouting operations.
Drilling Flexibility
The system adapts to various geological conditions with flexible drilling method switching: mud drilling for soft formations and pneumatic downhole hammer drilling for rock formations.
Technical Specifications
| Drilling Type |
Mud pump drilling and air DTH drilling |
| Geology Compatibility |
All geological formations |
| Operating System |
Hydraulic |
| Drilling Diameter (mm) |
115-350 |
| Drilling Depth (m) |
200 |
| Work Pressure (Mpa) |
1.05-3.5 |
| Air Consumption (m³/min) |
16-40 |
| Drill Pipe Length (m) |
3 |
| Drill Pipe Diameter (mm) |
89 |
| Axle Pressure (N) |
57,000 |
| Lifting Power (T) |
12 |
| Rotary Torque (Nm) |
5,600 |
| Rotary Speed (rpm) |
0-100 |
| Truck Chassis |
DONGFENG |
| Emission Standard |
Euro III |
| Horsepower |
180 HP |
| Rated Speed |
2,500 r/min |
| Fuel Type |
Diesel |
| Tire Size |
90.00-20R |
| Drive Form |
4×2 |
| Dimensions (mm) |
8,900 × 2,100 × 3,300 |
| Total Weight (T) |
12 |
Key Advantages
Precise Hydraulic Control System
Advanced fully hydraulic real-time adjustment system provides flexible parameter control for speed and torque. The top-drive design reduces drill pipe operation time, while the axial pressure regulating valve optimizes deep drilling efficiency for maximum productivity.
Multi-Mode Drilling Capability
Supports multiple drilling methods including air down-the-hole hammer and mud circulation. Available auxiliary pump sets enable seamless process switching between soft and hard geological formations, covering diverse operational requirements.
Robust Performance & Safety
Powered by a 260 HP engine mounted on a 6×4 Dongfeng truck chassis for superior mobility. Integrated safety features include lifting arm limiters and cylinder protectors, ensuring operational safety and equipment longevity.
Equipment Gallery
Manufacturer Profile
Henan Rancheng Machinery Co., LTD is a professional drilling equipment manufacturer in China, specializing in water well drilling rigs, rotary drilling rigs, anchor drilling rigs, core drilling rigs, DTH drilling rigs, solar pile drivers, mud pumps, air compressors, and drilling tools. With advanced technology, modern equipment, and experienced engineering teams, our products hold ISO9001 and CE certifications and are exported to over 200 countries worldwide, receiving excellent customer feedback. We operate on the principle of "Customer First, Integrity First" and look forward to successful cooperation.
