Product Description

RCF350T Truck-Mounted Water Well Drilling Rig - 350 Meter Depth Capacity

The RCF350T deep water well drilling rig represents our latest generation of down-the-hole drilling equipment. Engineered with a high-power air compressor for enhanced drilling speed, this model incorporates advanced hydraulic technology to deliver low energy consumption, high torque output, and simplified hole position adjustment. Ideal for resource exploration, hydrological wells, domestic water supplies, and agricultural irrigation applications.

Constructed with premium materials and featuring an efficient, compact design, the RCF350T ensures stable operation with minimal downtime. Its proven reliability and exceptional user experience have earned widespread market acceptance and positive customer feedback.

Technical Specifications

Parameter	Specification
Drilling Type	Mud pump drilling and air DTH drilling
Geology Compatibility	All types
Drill System & Operation	Hydraulic
Drilling Diameter (mm)	115-350
Drilling Depth (m)	350
Work Pressure (Mpa)	1.05-3.5
Consumption (m³/min)	16-40
Drill Pipe Length (m)	3
Drill Pipe Diameter (mm)	89
Axle Pressure (N)	57,000
Lifting Power (T)	24T
Rotary Torque (Nm)	6,200
Rotary Speed	0-100
Truck Chassis	HOWO
Diesel Engine Model	Cu-mmins
Discharge Standard	Euro III
Horsepower	180HP
Rated Speed	2,500r/min
Fuel Type	Diesel
Tire Size	90.00-20R
Drive Form	6×4
Dimension (mm)	10,600×2,500×3,550
Total Weight (T)	23

Key Advantages

Convenient Operation & Strong Adaptability: Full hydraulic control enables flexible parameter adjustment. Top-drive rotary propulsion simplifies drill pipe handling, reducing auxiliary time. Supports multiple drilling processes including air DTH and mud circulation with optional equipment for diverse construction conditions.
High Efficiency & Low Consumption: Advanced hydraulic system with premium core components delivers fast drilling speeds and high operational efficiency. DTH technology reduces per-meter construction costs while maintaining low failure rates and easy maintenance for exceptional cost-effectiveness.
Stable, Durable & Reliable: HOWO truck chassis with high-power engine, combined with patented composite boom and tower design, provides superior lifting capacity and operational stability. Integrated safety features including boom limiters and oil pipe protection ensure both operational safety and extended equipment lifespan for demanding construction environments.

Product Gallery

Manufacturer Profile

Henan Rancheng Machinery Co., LTD is a professional drilling rig supplier in China, specializing in the design and manufacture of water well drilling rigs, rotary drilling rigs, anchor drilling rigs, core drilling rigs, DTH drilling rigs, solar pile drivers, mud pumps, air compressors, and drilling tools. With advanced technology, modern equipment, experienced teams, and ISO9001 and CE certifications, our products are exported to approximately 200 countries worldwide, receiving excellent customer feedback. We adhere to the principle of "Customer First, Integrity First" and look forward to cooperating with you.
