RCF180S Mini Water Well Drilling Machine For Economic And Durable

RCF180S Mini Water Well Drilling Machine For Economic And Durable

Economic Mini Water Well Drilling Machine

Durable Mini Water Well Drilling Machine

RCF180S Mini Water Well Drilling Machine

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCF180S

Contact Us
Request A Quote
RCF180S Mini Water Well Drilling Machine For Economic And Durable
RCF180S Mini Water Well Drilling Machine For Economic And Durable RCF180S Mini Water Well Drilling Machine For Economic And Durable RCF180S Mini Water Well Drilling Machine For Economic And Durable RCF180S Mini Water Well Drilling Machine For Economic And Durable
Product Details
Name:
RCF180S
Drilling Depth:
180m
Once-time Advance Length:
90-300mm
Rotary Speed:
45-65r/min
Diesel Engine:
77.3KW Yuchai Engine
Max Torque Of Rotary:
4000-4600Nm
RCF180S Mini Water Drilling Machine Is Very Powerful ,it Can Drill Max 180m Depth , This Small Water:
76/89mm
Highlight:

Economic Mini Water Well Drilling Machine

,

Durable Mini Water Well Drilling Machine

,

RCF180S Mini Water Well Drilling Machine

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
It can be shipped by one 20" container
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
RELATED PRODUCTS
Good price Crawler Type Hydraulic Water Well Drilling Rig For Core Drilling Rig Home Water Well Equipment 150m Depth online Video

Crawler Type Hydraulic Water Well Drilling Rig For Core Drilling Rig Home Water Well Equipment 150m Depth

Get Best Price
Good price RCF150S Water Well Drilling Machine with 150m Drilling Depth and 17-31m sup3 online Video

RCF150S Water Well Drilling Machine with 150m Drilling Depth and 17-31m sup3

Get Best Price
Good price 500m Hydraulic Water Well Drilling Rig For Water Well Borehole Core Mining RC Drilling Machine online Video

500m Hydraulic Water Well Drilling Rig For Water Well Borehole Core Mining RC Drilling Machine

Get Best Price
Good price 150m Hydraulic Water Well Drilling Machine For 17 - 31m³/Min Air Consumption online Video

150m Hydraulic Water Well Drilling Machine For 17 - 31m³/Min Air Consumption

Get Best Price
Contact Us
Contact Now
Product Description

RCF180S Mini Water Well Drilling Machine for Economic and Durable


Machine Description


The RCF180S mini water drilling machine is very powerful, capable of drilling up to a maximum depth of 180 meters. This compact water drilling machine is equipped with a robust 77.3 kW Yuchai diesel engine, ensuring strong power for efficient operation. The machine has a maximum torque of 4600 N·m at the rotary head and a lifting capacity of 15 tons. Despite its small size, it offers impressive drilling capabilities. This water drilling machine uses 2-meter-long drilling rods, making it convenient to load and unload them.


Technical Parameters

Bore diameter(hammer) 90-300mm
Bore depth 180m
Air consumption 17-31m³/min
Air pressure 1.7-2.5Mpa
Once-time advance length 2.4m
Pipe diameter 76mm/89mm
Pipe length 2m
Push force 4T
Lifting force 15T
Max torque of rotary 4000-4600Nm
Rotary speed 45-65r/min
Mud Pump flow 200L/min (option)
Feeding efficiency 10-35m/h
Travel speed 2.5Km/h
Climb ability 30°
Dimension(L*W*H) 2300×1200×1900mm
weight 2700kg
Diesel engine 77.3KW Yuchai engine



Feature:

1,Small size, light weight ,Compact structure,and flexible operation.
this drilling machine weight is only 2700KGS ,the machine size is 2300X1200X2900mm.
2,it is DTH pneumatic water drilling rig ,two motors rotary head ,top driving ,drill with both mud pump and air compressor ,The double rotation motor increased the rotary torque and revolving speed.
3,big powerful and ability ,it use 77.3KW Yuchai engine ,it can drill max 180m depth ,90-300mm borehole.
4,it is rubber crawler mounted type ,easy to move.
5,full hydraulic legs ,very convenient to transport by truck ,very stable in drilling job.


Image Display



RCF180S Mini Water Well Drilling Machine For Economic And Durable 0RCF180S Mini Water Well Drilling Machine For Economic And Durable 1RCF180S Mini Water Well Drilling Machine For Economic And Durable 2
RCF180S Mini Water Well Drilling Machine For Economic And Durable 3
