Product Description

RCF300C Steel Track-Mounted Hydraulic Drilling Rig For Well Drilling

Europe Best Selling 300m High Quality Water Well Drilling Machinery with CE

The RCF300C deep well drilling rig features advanced hydraulic technology and a top-drive system, offering powerful torque, compact structure, and a mast with adjustable compensation for excellent drilling stability. Suitable for various drilling applications including irrigation, domestic/civil water supply, geothermal, hydrological, and industrial projects.

Core advantages include full hydraulic control, top-drive rotary propulsion, and multi-functional drilling capabilities. With optional auxiliary equipment, it offers high operating efficiency and controllable costs. The high-position outboard support facilitates loading and unloading, and the professional excavator chassis is adapted for complex and muddy environments.

This drilling rig boasts high-end configuration with main components and hydraulic systems from renowned brands. The main frame is constructed from high-strength, low-carbon alloy steel for durability and wear resistance. The parallel gearbox design ensures efficient power distribution, and the hydraulic system is easy to maintain.

Technical Specifications

Parameter	Specification
Model	RCF300C
Bore diameter (Hammer)	100-350mm
Bore depth	300m
Air consumption	17-35m³/min
Air pressure	1.7-3.0Mpa
Pipe diameter	89mm/102mm
Pipe length	1m/2m/3m
Lifting force	18T
Lifting speed	3m/min
Feeding speed	0.5-5m/min
Fast lifting speed	30m/min
Fast feeding speed	50m/min
Max torque of the rotary	7000-9000Nm
Rotary speed	40-70r/min
Hoist lifting capacity	2T
Mud Pump flow	450L/min (option)
High hydraulic leg	1.5m
Feeding efficiency	10-35m/h
Travel speed	2.5Km/h
Climb ability	30°
Dimension (L×W×H)	4200×2200×2600mm
Weight	7200Kg
Diesel engine	85KW Yuchai engine
Drilling way	Air compressor drilling or mud pump drilling

Key Advantages

Advanced fully hydraulic control system and top-drive system offering high rotational torque and flexible parameter adjustment for compatibility with various drilling tools and processes
Professional excavator chassis with high-position outboard hydraulic outriggers ensures smooth operation in muddy conditions without requiring crane assistance for loading/unloading
Supports multiple drilling methods including air down-the-hole hammer and mud circulation, with optional mud pumps and generators for diverse applications
Top-drive design reduces drill pipe loading/unloading time while composite mast with 18-ton lifting capacity improves operational efficiency
Core components and hydraulic system from well-known brands with main frame constructed from high-strength, low-carbon alloy steel for durability
Unique parallel gearbox oil pump design provides ample power distribution with low maintenance costs
75.8 kW Yuchai engine delivers stable power for extended service life
