Fuel saving:
The 200-type drilling rig uses the tractor as a carrier and hydraulics as the working power of the drilling rig. With only the 40HP power of the tractor's own diesel engine, it can easily achieve 200 meters of drilling. At the same time, there is no need to turn on the air compressor when lifting the rod. You only need to turn on the hydraulic power to lift the rod. Therefore, the drilling cost is lower and the economic benefit is higher.
Keyboard operation, wireless control:
The machine adopts mechatronics technology and uses a key keyboard to operate the drilling rig. The operation method is simpler and more flexible. The operator can freely choose the workstation position according to his own wishes, without being restricted by the drilling rig, and can realize instantaneous jog operation. The improved version realizes wireless remote control operation, which is more convenient to operate.
Save manpower:
Only two people are needed to operate the drilling rig - control the equipment and change the rod to complete all the work, saving manpower.
Simultaneous casing:
The drilling rig can drill and casing at the same time, and the drilling rig is equipped with a quick connection plug for the drill rod platform
Technical Parameters:
| Product Name: |
2000mm Feed Stroke Borehole Drilling Machine With 260m Depth Hydraulic Trailer Mounted Water Well Drilling Rig |
| Lifting Force: |
12t |
| Output Torque (n.m): |
5000 - 5500 |
| Rod Length (mm): |
2000 |
| Weight: |
4500kg |
| Rod Diameter (mm): |
76 & 89 |
| Travelling Speed (km/h): |
30 |
| Air Pressure (Mpa): |
1.7 - 2.5 |
| Rotation Speed (rpm): |
45 - 65 |
| Bore Depth: |
260m |
Support and Services:
1,24/7 service by chat online and phone.
2,Lifelong and free technical support.
3,Service overseas: if you need, we can dispatch an engineer to your door.
FAQ:
Q:Are you the manufacturer?
A: Yes, we are the factory with more than 10 years of manufacturing experience.
Q:What is the warranty of our machine?
A:Our main machine enjoys a 1 year warranty. And we provide videos for machine install and operation.
Q: How long is your delivery time?
A: About 10-15 work days after receipt of the payment.
Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefits;
Q:Do you have any certificates for your machine?
A: All of our products coming with the certificates of CE and ISO 9001:2000.
