Name: Full Hydraulic Tractor Mounted Water Well Drilling Rig 300m Depth
Brand: Henan Rancheng Machinery Co., Ltd.
SKU: RCF300WT
Price: 25,000.00 USD
Availability: InStock

Home > products > Borehole Drilling Machine >

Full Hydraulic Tractor Mounted Water Well Drilling Rig 300m Depth

Hydraulic water well drilling rig

Tractor mounted drilling machine

300m depth borehole rig

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCF300WT

Request A Quote

Product Details

Model:

RCF300WT

Drill Diameter:

140-300mm

Drill Depth:

300mm

Rod Diameter (mm):

76 & 89

Rod Length (mm):

3000

Lifting Force (t):

Rotation Speed (rpm):

45-70

Highlight:

Hydraulic water well drilling rig

Tractor mounted drilling machine

300m depth borehole rig

Payment & Shipping Terms

Minimum Order Quantity

Price

$20000-30000

Packaging Details

Standard shipping

Delivery Time

10-15 working days

Payment Terms

T/T, Western Union

Supply Ability

100sets per Month

Full Hydraulic Tractor Mounted Water Well Drilling Rig 300m Depth

Get Best Price

Video

RCF220W Hydraulic Borehole Drilling Machine for Hydrology Wells - 220m Depth

Get Best Price

Video

Full Hydraulic 300m Trailer Mounted Water Well Drilling Rig 4x4

Get Best Price

Video

200m Depth Hydraulic Small Borehole Drilling Rig Mutil Functional 90°～75° Drilling Angle

Get Best Price

Contact Now

Product Description

Full Hydraulic Tractor Mounted Water Well Drilling Rig 300m Depth

Product Specifications

Attribute	Value
Model	RCF300WT
Drill Diameter	140-300mm
Drill Depth	300mm
Rod Diameter (mm)	76 & 89
Rod Length (mm)	3000
Lifting Force (t)	18
Rotation Speed (rpm)	45-70

Product Overview

The RCF300WT tractor mounted deep water well drilling rig is a product independently developed by our company. The new generation of down-the-hole hammer combined with higher pneumatic power plays an important role in increasing the drilling speed. Adopting the latest model and advanced hydraulic technology, it has low energy consumption, large rotary torque and convenient drilling deviation.

Technical Parameters

Parameter	Value
Weight (t)	5T
Hole Diameter (mm)	140 - 300
Depth (m)	300
Feed Stroke (mm)	3400
Travelling Speed (km/h)	30
Climbing Angle	25 Degree
Tractor Horse Power (hp)	100HP Dongfanghong brand
Air Pressure (Mpa)	1.7 - 2.5
Air Consumption (m³/min)	17 - 31
Output Torque (n.m)	5000 -5500
Dimension (mm)	400020002700

Applications

This water well drilling rig is mainly used for:

Geothermal drilling
Farmland irrigation
Home yard and garden water well drilling
Piling of small buildings such as farmhouses or factories

With a drilling diameter of 70-350 mm and drilling depth of 100-300 meters for water wells, and up to 500 mm diameter with 60+ meters depth for piling applications.

Product Gallery
