14 Mpa Hydraulic System Rated Pressure Engineering Drilling Rig Anchor Drilling Rig For 40-60m Drilling Depth

14 Mpa Hydraulic System Rated Pressure Engineering Drilling Rig Anchor Drilling Rig For 40-60m Drilling Depth

14 Mpa Hydraulic System Drilling Rig

Anchor Drilling Rig

60m Depth Drilling Rig

Place of Origin:

China

Brand Name:

RanCheng

Certification:

CE, ISO 9001:2000

Model Number:

RCA-40E

Contact Us
Request A Quote
Product Details
Power Head Stroke:
1200mm
Applications:
Construction Of Big Tonnage Stress Anchoring Hole For Water Power Station, Railway, Highway, Drainage Hole And Geologic Calamity Fathering For Landslide Prevention And Rock Collapse, Drilling Small Size Water Well And High-pressure Jet Grouting Hole
Rig Weight:
320kg
Hammer Size:
90 Or 110
Mast Slip Stroke:
500 Mm
Hydraulic System Rated Pressure:
14 Mpa
Drilling Tilt Angle:
0 - 120 °
Drill Specifications:
¢ 60X1000mm, ¢ 76X1000mm
Highlight:

14 Mpa Hydraulic System Drilling Rig

,

Anchor Drilling Rig

,

60m Depth Drilling Rig

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Standard shipping
Delivery Time
10-15 working days
Payment Terms
T/T, Western Union
Supply Ability
100sets per Month
Product Description

14 Mpa Hydraulic System Rated Pressure Engineering Drilling Rig Anchor Drilling Rig For 40-60m Drilling Depth

Product Description:

With a drilling diameter of 90-150 mm, this drilling rig is suited for a wide range of drilling requirements and can easily penetrate through tough soil and rock formations. The power head maximum pull force of 25 kN ensures that the machine can handle heavy-duty drilling tasks with ease.

The drilling depth of 40-60m makes this rig an ideal choice for deep drilling applications. Whether you need to drill for soil stabilization, foundation reinforcement, or other construction and engineering purposes, this drilling rig is up to the task.

Our Engineering Drilling Rig comes with drill specifications of ¢ 60X1000mm and ¢ 76X1000mm, making it easy to customize the drilling process according to your specific requirements. The machine is designed to be user-friendly, and the controls are easy to operate, even for novice users.



Features:

  • Product Name: 14 Mpa Hydraulic System Rated Pressure Engineering Drilling Rig Anchor Drilling Rig For 40-60m Drilling Depth
  • Product Category: Engineering Drilling Rig
  • Drilling Tilt Angle: 0 - 120 °
  • Electric Motor Power: 7.5KW
  • Features:
    • Great drilling capability
    • Wide range of application
    • Rapid drilling speed and high drilling efficiency
    • Powerful ability of eliminating accident
    • Extension mechanism in the output spindle of top drive power head
    • Front-mounted adjustable columns on drill frame
    • Separate group design
    • Hydraulic drive and operation
    • Suitable for various drilling methods

This soil nailing drilling equipment, soil nailing drilling equipment, anchor drilling machine is a powerful and versatile drilling rig that can handle a variety of drilling methods. With its wide range of application and rapid drilling speed, it's perfect for drilling in any soil or rock conditions. The rig also features a powerful ability to eliminate accidents, making it a safe choice for any drilling project. Its separate group design and hydraulic drive and operation make it easy to use, while its extension mechanism in the output spindle of top drive power head and front-mounted adjustable columns on drill frame make it highly efficient.



Technical Parameters:

Product Attribute Value
Product Name Engineering Drilling Rig
Hammer Size 90 or 110
Electric Motor Power 7.5KW
Power Head Output Speed 0 ~-80 Rpm
Features Great drilling capability, wide range of application, rapid drilling speed and high drilling efficiency, powerful ability of eliminating accident, extension mechanism in the output spindle of top drive power head, front-mounted adjustable columns on drill frame, separate group design, hydraulic drive and operation, suitable for various drilling methods
Drill Specifications ¢ 60X1000mm, ¢ 76X1000mm
Rig Weight 320kg
Drilling Tilt Angle 0 - 120 °
Mast Slip Stroke 500 mm
Power Head Stroke 1200mm
Hydraulic System Rated Pressure 14 Mpa
Keywords rock anchor drilling machine, soil nailing drilling equipment, hydraulic anchor drilling rig


Applications:

The RanCheng RCF80GP Engineering Drilling Rig is a top-of-the-line machine that is perfect for soil nailing drilling equipment, anchor drilling machine, and other soil nailing drilling equipment applications. This product is made in China and has been certified with CE and ISO 9001:2000.

The RCA-40E is equipped with a powerful engine and has a drilling capability of ¢ 60X1000mm and ¢ 76X1000mm. It has a wide range of applications and has a rapid drilling speed with high drilling efficiency. With its powerful ability to eliminate accidents, you can rest assured that your work will be safe and productive.

The extension mechanism in the output spindle of top drive power head and the front-mounted adjustable columns on the drill frame make this machine highly versatile. The separate group design, hydraulic drive, and operation make it easy to use and suitable for various drilling methods.

FAQ:

Q:Are you the manufacturer?

A: Yes, we are the factory with more than 10 years of manufacturing experience.

Q:What is the warranty of our machine?
A:Our main machine enjoys a 1 year warranty. And we provide videos for machine install and operation.

Q: How long is your delivery time?
A: About 10-15 work days after receipt of the payment.


Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefits;

Q:Do you have any certificates for your machine?
A: All of our products coming with the certificates of CE and ISO 9001:2000.



14 Mpa Hydraulic System Rated Pressure Engineering Drilling Rig Anchor Drilling Rig For 40-60m Drilling Depth 0

14 Mpa Hydraulic System Rated Pressure Engineering Drilling Rig Anchor Drilling Rig For 40-60m Drilling Depth 1

14 Mpa Hydraulic System Rated Pressure Engineering Drilling Rig Anchor Drilling Rig For 40-60m Drilling Depth 2

14 Mpa Hydraulic System Rated Pressure Engineering Drilling Rig Anchor Drilling Rig For 40-60m Drilling Depth 3
